Explosion proof heat pipe heatsinks for Mining
Application: cool IGBT module in converter in the flooded mine
Cooling mode: natural cooling
Heat radiation power: 6000W
Temperature rise: 40ºC
Thermal resistance:0.0067 ºC/W
Heat pipe heatsinks for electric locomotive
Application: main converter and auxiliary power supply for traction electric locomotive
Cooling mode: natural cooling
Heat radiation power
Temperature rise
Thermal resistance
Heat pipe heatsinks for SVG
Application: Dynamic reactive power compensation device for power system
Cooling mode: natural cooling
Heat radiation power: 500～2000W
Temperature rise: 40ºC
Thermal resistance：0.08～0.02 ºC/W
Heat pipe heatsinks for electrical-controlled appliance
Cooling mode: forced air cooling
Heat radiation power:2000～3500W
Temperature rise: 40ºC
Thermal resistance:0.02～0.011 ºC/W
Heat pipe Heat Radiation Type Three-phase controllable Rectification Equipment
Application: DC motor speed regulation and DC source voltage regulation. It is widely applied in metallurgy, mechanical, and coal industries.
Feature: Lower rotating speed of fan with small noise, excellent cooling effect.
